Visure Requirements ALM Platform – System Requirements
Visure Requirements ALM Repositories
The commercial open databases supported by Visure Requirements ALM are the following:
- Microsoft SQL Server:2008, 2012, 2014,2016
- ORACLE: 10, 11, 12C,18C
- Microsoft Access: 2007, 2010 (not supported for production environments)
For smaller deployments, with a relatively small number of items (< 5000 items) and concurrent users (< 5 concurrent users) the following databases are currently supported:
- SQL Server Express
- Oracle Database Express
These databases have built-in performance restrictions. Visure highly encourages to review these restrictions before deploying them.
The migration between any of these databases is fully supported within Visure Requirements.
Visure Requirements ALM Client
Hardware requirements
| Processor: | Multicore processor recommended for better performance (INTEL I3 or higher) | |
| Hard Disk Drive: | 16 GB minimum free space | |
| RAM memory: | 1 GB is the minimum free memory required. 2 GB of free memory is recommended. – For large repositories, 2 GB is the minimum required: More than 10 projects with more than 5.000 items per project, with the average size of the RTF descriptions (~ 3MB). – Any number of projects with an average of extra-large RTF descriptions (~ 10MB). |
Software requirements
Supported Operating Systems
- Microsoft Windows Server 2008 / Microsoft Windows Server 2008 R2
- Microsoft Windows Server 2012 / Microsoft Windows Server 2012 R2
- Microsoft Windows Server 2016
- Microsoft Windows 7: 32 and 64-bit
- Microsoft Windows 8: 32 and 64-bit
- Microsoft Windows 10: 32 and 64-bit
Note: it is necessary to log in the system with Administration rights to successfully install the product. In Windows 7 and Windows 8 the installer must be executed using the option “Run as administrator” (right click on the installer and select this option).
Supported ODBC Drivers
Depending on the database engine selected to store the VR repository, the corresponding supported ODBC driver version is required (only 32-bit ODBC drivers are supported):
| Version | ODBC Supported drivers | |
|---|---|---|
| Microsoft SQL Server | 2005 | SQL Native Client 9.0 |
| 2008 | SQL Native Client 10.0 | |
| 2012, 2014 | SQL Native Client 11.0 | |
| 2016, 2017 | SQL Native Client 13.1 | |
| Oracle | 10 | 10.2.0.5 Driver versions with known issues that may cause malfunctions in VR: 10.1.0.X (all versions with X < 31) 11.2.0.1 (in Windows 7 64-bit and Windows 8 64-bit) |
| 11 | 11.2.0.4 | |
| 12 | 12.2 | |
| Microsoft Access | 2007 | Microsoft Access Driver (6.01.7601.17632) |
| 2010 | Microsoft Access Driver (6.01.7601.17632) |
Visure Requirements ALM License Server
The installation of the Visure License Server is required only if floatinglicenses are used. Only one Visure License Server installation will be necessary for all Visure Requirements ALM users.
The Visure License Server must be installed in a Windows Server 2008 (32 or 64-bit), Windows Server 2012 (32 or 64-bit), Windows Server 2016 (32 or 64-bit), Windows 7 (32 or 64-bit) or Windows 8 (32 or 64-bit) or Windows 10 (32 or 64 bit) with Administration rights.
By default Visure License Server uses port 6200(this can be changed) for communication with client installations, so this port is need to be opened.
Communication Requirements
1 GB/10 GB LAN between the VR clients and the Visure repository. There must be bidirectional communication via TCP/IP between the License Server and the VR clients. For further details on how to install Visure Requirements, please review Visure Requirements ALM System Requirements.
For medium-to-large deployments, a client virtualization solution is recommended. Please contact us to discuss various possibilities.
